Tesla coils, microcontrollers, and whatever else is on the bench.
Ask why the board keeps resetting, or where the smoke came from, and get an answer from someone who made the same mistake before you. Microcontrollers and embedded, Tesla coils and high voltage, power electronics, old machines, and the tools that keep them running. Everyone here was a beginner once.
To date: 3 threads, 1 reply, 14 members.
“The first few times, only run it for a couple of seconds and then feel the heatsink.”
The boards
Loading the boards.
The people behind the drivers
From Tesla himself to today's builders. Each has a page with photographs, sources and the builds they have on the driver tree.
- Nikola TeslaThe first builder. Every coil on these three trees goes back to his 1891 patent for a resonant air-core transformer, and he built the biggest one without a single transistor.
- Richie BurnettBuilt and wrote up the first solid-state coil that performed, in May 2000: a primary driven straight from the bridge, run from four supplies, with photographs of what each envelope did to the spark. By Anders Mikkelsen's account he also ran the first QCW experiments.
- Steve WardOn all three trees: first SSTC in 2003, the DRSSTC design guide in 2005, the Universal Driver in 2008, the first deliberate QCW in 2010.
- Gao GuangyanWrote the pages a generation of builders learned from: four SSTCs, three DRSSTCs, UD2.7 as a kit, and the first fully documented QCW builds.
- Anders MikkelsenSelf-oscillating SiC drivers, APWM ramping without a buck, and arcs over three metres off a 16 cm winding, all published as he went.
- Steve ConnerAn independent DRSSTC line from 2005: the CD4046 PLL driver, a tuning trick that keeps primary current in check on a ground strike, and the pulse-skip idea for ramping.
- Jens KerrinnesTook the Universal Driver onto a microcontroller: UD3, with autotune, MIDI, a command line and a frequency sweep built in.
- Daniel MarksUD2.9: the UD2.7C rebuilt through-hole with a pulse-skip jumper, released under CC-BY-SA so anyone who would rather solder than reflow can build it.
- Daniël EindhovenRAIKIRI, a battery staff with a 1200 V SiC full bridge run as APWM and a ramp scaled to the bus: 350 cm of arc off a 14 cm winding, the longest on the records wall.
Caution. Tesla coils run at lethal voltages. Every guide leads with the danger, and advice that can hurt you carries a warning. Read the safety guide.
